PARK ENGINEERING

SMALL, POWERFUL, COMPACT, HIGH EFFICIENCY

AC GEAR MOTORS

We introduce our various wide range AC GEAR MOTOR with high torque & efficiency.
MOTOR-PARK gearmotors will give you enough satisfaction
and happiness for your needs.
Application : conveyor automation system, robot, general industries.

SMALL, POWERFUL, COMPACT, HIGH EFFICIENCY

DC GEAR MOTOR, ACTUATOR

SMALL, POWERFUL, COMPACT, HIGH EFFICIENCY

MIGHTY WORM GEARBOX

SMALL, POWERFUL, COMPACT, HIGH EFFICIENCY

AC STANDARD GEAR MOTOR

SHADED POLE GEAR MOTOR

SHADED POLE INDUCTION GEARED MOTOR (B.B.Q Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6122A	2	120	60	0.33	15.5	40	7.0	10.0	ㅁ61 X 12t	8
DAG-6122B	2	220	60	0.16	16.0	50	8.0	9.8	ㅁ61 X 12t	8

SHADED POLE INDUCTION GEARED MOTOR (Slot Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6152A	2	120	60	0.15	9.6	6	22.6	67.2	ㅁ61 X 15t	8
DAG-6152B	2	220	60	0.08	9.5	6	22.5	67.5	ㅁ61 X 15t	8
DAG-6152C	2	230	50	0.10	10.9	5	31.7	76.8	ㅁ61 X 15t	8

SHADED POLE INDUCTION GEARED MOTOR (Slot Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6202A	2	220	60	0.33	25.6	25	22.5	52.4	ㅁ61 X 20t	8
DAG-6302A	2	220	60	0.30	33.5	11	46.0	81.0	ㅁ61 X 20t	8
DAG-6302B	2	220	60	0.36	39.0	30	19.0	41.5	ㅁ61 X 30t	8
DAG-6402A	2	220	60	0.29	33.0	74	10.5	18.6	ㅁ61 X 40t	8

SHADED POLE INDUCTION GEARED MOTOR (Carrier Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6302C	2	120	60	0.95	50.0	98	12.2	20.5	ㅁ61 X 30t	8
DAG-6302D	2	220	60	0.44	48.5	44	27.6	45.5	ㅁ61 X 30t	8

SHADED POLE INDUCTION GEARED MOTOR (Ice Slush Mashine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6402B	2	120	60	0.85	42.5	42	20.3	42.7	ㅁ61 X 40t	12
DAG-6402C	2	220	60	0.40	40.0	42	20.6	42.0	ㅁ61 X 50t	12
DAG-6402D	2	220	50	0.45	41.0	35	20.9	44.4	ㅁ61 X 40t	12

SHADED POLE INDUCTION GEARED MOTOR (Carrier Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6402G	2	220	60	0.38	40.6	8	225	458	ㅁ61 X 40t	16
DAG-6402A	2	230	50	0.42	43.2	3	434	667	ㅁ61 X 50t	16

SHADED POLE INDUCTION GEARED MOTOR (Ice Dispenser)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	INPUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6402G	2	120	60	3.50	1003	28	63	170	ㅁ61 X 40t	9.5
DAG-6402A	2	220	50	1.90	91.5	28	65	162	ㅁ61 X 50t	9.5
DAG-6402B	2	230	50	1.80	104.2	23	76	165	ㅁ61 X 50t	9.5

SHADE POLE INDUCTION GEARED MOTOR (Carrier Machine)

MODEL	POLE	VOLTAGE	FREQUENCY	NO LOAD (At gear ass'y)					CORE SIZE	SAHFT (ø)
	POLE	VOLTAGE	FREQUENCY	CURRENT	IN PUT	SPEED	STARING TORQUE	PEAK TORQUE
	P	V	Hz	A	W	RPM	Kg.cm	Kg.cm
DAG-6502C	2	220	60	0.50	55.3	6	275	595	ㅁ61 X 50t	12.7
DAG-6502D	2	230	50	0.66	67.6	5	384	685	ㅁ61 X 50t	12.7
